Alfa Romeo 75 1985-1992 Workshop Manual | PDF Download
The Alfa 75 was the last rear-drive Alfa saloon, and this manual follows it through its complete life, from the early carburettor cars to the Motronic fuel-injected models and the Twin Spark. Every engine is here, along with the gearbox, the brakes and the suspension. There's over 1000 pages of information.
Each job is broken into removal, checks and refitting, with specifications and tightening torques at the end of every section. There are also fault-finding charts for the engine, fuel system, gearbox, steering and brakes, and electrical checks that use a test instrument, so you can trace a problem before you start taking parts off.
Models covered:
- Alfa Romeo 75 1.6
- Alfa Romeo 75 1.8
- Alfa Romeo 75 1.8 Turbo
- Alfa Romeo 75 2.0 (carburettor and Motronic fuel injection)
- Alfa Romeo 75 2.0 Twin Spark
Engines:
- 1.6, 1.8 and 2.0 litre four cylinder, carburettor
- 2.0 litre four cylinder, Motronic fuel injection
- 1.8 litre four cylinder, turbocharged
- 2.0 litre Twin Spark
Transmission:
- 5-speed manual
What’s included:
- Complete car: dimensions, weights, identification labels and vehicle numbers, maintenance schedule, fluids and lubricants, refill capacities, jacking and towing points, special tools
- Engine: removal and refitting, dismantling, checks, reassembly, cylinder head, valves, pistons and cylinder liners, crankshaft, timing chain and timing variator, lubrication system, valve clearance adjustment, specifications and torques, fault finding
- Fuel system: Weber, Solex and Dellorto carburettors, Motronic ML4.1 fuel injection, air intake, fuel tank, fuel pumps, injectors, fuel pressure regulator, exhaust, catalytic converter, Lambda sensor, fuel vapour system, idle and mixture settings
- Ignition, starting and charging: ignition timing, spark plugs, starter motor, alternator
- Cooling system: radiator, water pump, thermostat, electric fans, antifreeze
- Clutch: clutch unit, removal and refitting, hydraulic system
- Gearbox and differential: gear control linkage, removal and installation, bench overhaul of rods and forks, shafts and gears, differential unit, service data
- Transmission and drive shafts: removal, overhaul, joints
- Front suspension and rear suspension: springs, shock absorbers, hubs and bearings, wheel alignment, ride height
- Brakes: front and rear brakes, master cylinder, servo, handbrake, bleeding, ABS Mark II anti-lock system
- Steering: steering column, adjustable column, power steering pump and fluid, mechanical steering, specifications
- Electrical: how to read the wiring diagrams, fuse and relay layouts, lighting, sensors and senders, wipers and washers, headlight washers, electric accessories, Motronic ignition and injection wiring diagram
- Instruments: instrument cluster and electronic instruments
- Body: sheet metal panels, doors, bonnet and boot lid, interior trim, exterior trim
- Heater and air conditioning
File Format: PDF
Language: English
Print: Print the complete manual or just the pages you require
Bookmarked: Bookmarked for easy navigation
Requirements: We recommend using Adobe PDF Reader for best results
Device: We recommend downloading to a PC or Laptop or visit our Download Help Page for further information regarding Smart Devices
